RT-A-1620MX5M

RT-A-1620MX5M

Specification Value
Focal length 16 (mm)
Image circle diameter 22.0 (mm)
Max sensor size 4/3″
4/3″ 67.4 (deg)
Working distance range 0.1 – inf (m)
f/N 2.0 – 32
Back focal length 21.6 (mm)
Distortion on 4/3″ 2.50 (%)
Iris control Manual
Focus control Manual
Mount C
Filter thread M72 x 0.75
Outer diameter 76.0 (mm)
Length 102.4 (mm)
Mass 690 (g)
Ajánlatot kérek
Kategória: Címke: Márka:

Leírás

  1. Working distance: distance between the front end of the mechanics and the object.
  2. Value calculated at the corner point of the sensor diagonal. For distortion graphs see datasheet
  3. Measured from the front end of the mechanics to the camera flange at infinite focusing.

További információk

Foglalat

C-mount
F/n

2.0 – 32
Color
Gyártó

Opto
Distortion on 4 3

2.50 (%)
Outer diameter

76.0 (mm)
Filter thread

M72 x 0.75
Focus control

Manual
Iris control

Manual
Back focal length

21.6 (mm)
Working distance range

0.1 – inf (m)
Fókusztáv

16 (mm)
Length

102.4 (mm)
Képkör

22.0 (mm)
Mass

690 (g)
Operation power source
Fókusztáv (intervallum

16
Szenzor méret

4/3"
